Intel® Pentium ® 4 or Celeron® (D) processor based PICMG 1.2 (ePCI-X) SHB with DDR SDRAM,VGA, Dual Gigabit Ethernet, Audio and USB 2.0

  • PICMG 1.2 SHB supports one PCI and one PCI-X (66MHz only); independent architecture of these two buses increase total bandwidth of expansion
  • High quality and reliable design for wider range Intel® Pentium® 4/Celeron® (D) (0.13 micron & 90 nm process) processor support mission critical operation
  • Support Mobile Intel® Pentium® 4-M processor for low power consumption application
  • Dual on-board Gigabit Ethernet for network redundancy application
  • Dual SATA port supports higher throughput storage deices
  • Standard features for embedded system deployment like H/W monitoring, WDT, SSD and Wake-On-LAN

Ordering Guide

Intel® Pentium® 4 or Celeron® (D) processor based PICMG 1.2 (ePCI-X) SHB with DDR SDRAM, VGA, dual Gigabit Ethernet, audio and USB 2.0

Packing List

  • PRN Cable with Bracket
  • IDE cable ULTRA ATA/66
  • SATA cable
  • Cable Assy 4F-4F 1007#26 400mm
  • Dual COM Port Cable w/Bracket
  • FDD Cable
  • Utility CD Driver with user's manual

Quote & Request Sales Request or Technical Request
  • Specifications are subject to change without notice.
  • Pentium® 4, Pentium® III, Pentium® II and Celeron® are registered trademarks of Intel® Corporation.
