| Model | PJAI-1100F | ||||
|---|---|---|---|---|---|
| Sys Form Factor | Proprietary | ||||
| General | ||||||
|---|---|---|---|---|---|---|
| Processor | NVIDIA® Jetson Orin™ NX 8GB | NVIDIA® Jetson Orin™ NX 16GB | ||||
| Memory | Support up to 16GB LPDDR5 on board | |||||
| Storage | 1 x M.2 Key-M NVMe PCIe x4 2280 | |||||
| System I/O | ||||||
|---|---|---|---|---|---|---|
| Ethernet | 2 x 1 GbE LAN | |||||
| Serial Port | 2 x COM Ports Support RS-232/422/485 | |||||
| 1 x CANbus FD | ||||||
| USB | 3 x USB 3.2 Gen2 x1 (10Gbps) Type A | |||||
| 1 x USB 3.2 Gen2 x1 (10Gbps) Type C | ||||||
| GPIO | 1 x 8-bit Digital I/Os | |||||
| Display | 1 x HDMI® 2.0b | |||||
| Other | Power Button, Reset Button, Recovery Button | |||||
| LED | Power, Storage | |||||
| Antenna | 6 x SMA Antenna holes for LTE / 5G / Wi-Fi | |||||
| SIM Slots | 2 x Nano-SIM | |||||
| Expansion I/O | ||||||
|---|---|---|---|---|---|---|
| M.2 | 1 x B Key w/ 3042/3052 | |||||
| 1 x E Key w/ 2230 | ||||||
| ME/Environment | ||||||
|---|---|---|---|---|---|---|
| Dimension (WxDxH) | 152 x 112 x 90 mm (5.98″ x 4.41″ x 3.54″ ) | |||||
| Weight | 1.61 kg | |||||
| Power Supply | Terminal Block 12~24V | |||||
| Mounting | Wall Mount | |||||
| Vibration | 1G 5~500Hz with Wall mount (IEC/EN 60068-2-6) | |||||
| Shock | 50G 11m sec with Wall mount (IEC/EN 60068-2-27) | |||||
| Operating Temperature | -20 ~ 60 °C (-4.0 ~ 140.0 °F) | |||||
| Storage Temperature | -40 ~ 85 °C (-40.0 ~ 185.0 °F) | |||||
| Cooling | System 1 x Fan | |||||
| BSP | 6.2 | |||||
| Relative Humidity | 5% to 95%, non-condensing | |||||
| Certification | CE/FCC/UKCA Class A | |||||
| OS | Linux™ | |||||
| Category | Product | P/N | Status | Description |
|---|---|---|---|---|
| System | PJAI-1100F-OX8G | AS5-3724 | Available | (R).ATO.PJAI-1100F-OX8G.Embedded System. NVIDIA Jetson Orin NX(8GB) (260pin SO-DIMM),12-24V |
| PJAI-1100F-OX16G | AS5-3725 | Available | (R).ATO.PJAI-1100F-OX16G.Embedded System. NVIDIA Jetson Orin NX(16GB) (260pin SO-DIMM),12-24V |
