With all the trends in networking, how could we fulfill the demands of

Low Latency, High Computing, High Bandwidth, More Connectivity, PoE
Support, and IP Security?

We bring you our answer:

ANS series, the Advanced Network Solutions.


Intel Platform

With Intel CPU platform, ANS series implements Intel Apollo Lake CPU with low power consumption and Intel Denverton CPU with high computing efficiency to fulfill the requirements from edge to server. And through the complete software support of the Intel ecosystem, it improves the support of third-party software applications.


In the system, in addition to the physical Copper & Fiber and Ethernet connection, it also supports rich wireless transmission interfaces such as WiFi, 3G, LTE module and LPWAN: LoRa, ZigBee. In the M.2 slot, PCIe and USB3.0 signals are reserved to directly support the future 5G module to improve the wireless transmission capability of the system.


In 1/2 width of the cabinet, it provides up to 12 high-density Ethernet GbE Ports. What’s more, 2x 10GbE Fiber Ports are euipped on Intel Denverton system to support more uplink network bandwidth.

Smart Design

Compare to the solutions with equivalent level in the market, ANS series is highly competitive with its up-to-12 LAN ports support. Dimension-wise, its compact design in size makes it feasible to configure two ANS devices in each rack unit.

IoT Solution

With the development of AI under mature IoT networks, edge-computing with powered devices enables us to implement the on-site solution and process the data in short time. ANS series provides 8-12 LAN ports, each of which can be upgraded as PoE. Not only does this scalability facilitate the construction of AIoT, but it also helps achieve the application of edge-computing in a cost-effective way.

Software & IPSec

For the IoT solution, the software development process can be shortened while maintenance efforts can be drastically reduced with our PoE API and GUI. To enhance the security of all types of infrastructures, Intel features DPDK and QAT in her latest product selections. As an experienced solution provider, we also can help our customers to accomplish the development via those resources.


Thank you for visiting Portwell. Our goal is to provide you with a competitive edge through value driven products and superior service. We are more than willing to answer your questions regarding our comprehensive product lines. Should you have any suggestions on our website, we are also pretty interested in your feedback.

Our basic contact info is available as below:

Portwell, Inc.

242, Bo-Ai Street, Shu-Lin Dist., New Taipei City 238, Taiwan


Omni SD-WAN Platform

  • Intel Atom® x5-E3940(4C)/ E3930(2C) Processor (Apollo Lake)
  • 2x GbE RJ45, 8x GbE RJ45 (with PoE+ support by SKU)
  • 1x RJ45 Console, 1x HDMI,2x USB3.0
  • 1x DDR3L 1866/1600/1333 MT/s ECC SO-DIMM up to 8GB
  • 1x eMMC 16GB(on-board), 1x TPM2.0 (on-board)
  • 1x Mini-PCIe(PCIe/ USB2.0), 1x M.2 Key-B Slot(PCIe/ USB3.0), 1x SATA III, 2x micro SIM
  • Design ready for 5G and WiFi 6 (802.11ax)
  • Compact design 2 in 1U rackmount



  • Intel Atom® C3758(8C)/ C3558(4C) Processor (Denverton)
  • 2x 10Gb SFP+, 1x GbE RJ45, 12x GbE RJ45 (with PoE+ support by SKU)
  • 1x RJ45 Console, 2x USB3.0
  • 2x DDR4 2400/2133 MT/s ECC SO-DIMM up to 32GB
  • 1x TPM2.0(on-board)
  • 1x Mini-PCIe(PCIe/ USB2.0), 1x M.2 Key-B Slot(PCIe/ USB3.0), 1x SATADOM
  • Design ready for 5G and WiFi 6 (802.11ax)
  • Compact design 2 in 1U rackmount



  • Intel Atom® C3436L(4C) / C3338R(2C) Processor (Denverton)
  • 8x GbE RJ45 1x RJ45 Console, 2x USB 3.0
  • 1x DDR4 1866 MT/s ECC and non-ECC SO-DIMM up to 32 GB
  • 1x TPM 2.0 (on-board)
  • 1x M.2 Key-E Slot (PCIe/ USB2.0), 1x M.2 Key-B Slot (PCIe/ USB3.0), 1x M.2 Key-M Slot (SATA)
  • Design ready for 5G and WiFi 6 (802.11ax)
  • Compact design 2 in 1U rackmoun
