The DTEC-6012-V / DTEC-6014-V builds on Intel® Core™ i3-7100U / i5-7300U low power processor technologies that can support DDR4 memory. Dual HDMI® display output, one M.2 socket . DTEC-6012-V / DTEC-6014-V is an ideal platform with rich I/O and high resolution for telemedicine and comply with IEC60601-1-2 makes it a perfect solution to control medical equipment.control medical equipment.
| Processor | Intel® Core™ i3-7100U,QC, 2.30 GHz, 15 W – Intel® Core™ i5-7300U, QC, 2.40 GHz, 15 W |
| BIOS | AMI uEFI BIOS |
| Memoy | SODIMM x 1, max. 16GB, DDR4 2133 non-ECC |
| Storage | 1x SATA III port |
| Expansion Interface | M.2 Key E (Supports 2230) – Mini PCIe (half size) |
| Serial Port | RS232 DB-9 connector x2 |
| USB | USB3.0 x4 |
| Audio | Audio Jack x 2: Line-in,Mic-in & Line-out |
| Ethernet | Gigabit LAN x1 |
| Display | 2x HDMI® : Supports max resolution up to 4Kx2K@30Hz |
| Power Input | DC 12V input with Power Adapter |
| Operation Temperature | 0°C ~ 40°C |
| Storage Temperature | – 40°C ~ 80°C |
| Dimension | 152(W) x 237.4(H) x 44(D) mm |
| Weight | 1.45 kg |
