COM Express Type 6標準模組化電腦搭載Intel第11代Core™ vPro與Xeon® W-11000E處理器,PCOM-B657VGL幫助您更簡單地邁向智慧製造!

PCOM-B657VGL image

Situation
Nowadays, as manufacturers face several challenges such as sudden crises or environmental change, turning into smart factory with industry 4.0 technology is a key path for them to survive and even grow up in the ever-changing age. However, before the industrial transformation, there are various complex digital transformation challenges to be overcome such as securely connecting the industrial edge to enterprise networks and simultaneously supporting both new and legacy OT systems, or deterministic communications from industrial endpoints to IT servers without impact on the safe and secure operation of OT endpoints in any way, etc.

Solutions
To accelerate the transformation of smart factory, besides software technology and infrastructure, suitable hardware with enough performance is the key to help its development. Portwell PCOM-B657VGL, a COM Express Type 6 basic module featuring 11th Generation Intel Core vPro and Xeon W-11000E Series processors which provide scalable computing power, safety, security, and real-time features, catches the key technical pillars of Industry 4.0-networking, performance, reliability, and security. It also helps you accelerate the development and deployment of your infrastructure and applications.

Featuring the latest 11th Generation Intel Core and Xeon W-11000E processors with Willow Cove 10nm++, PCOM-B657VGL delivers 65% faster single-thread and multi-tasking compute-intensive applications for workload consolidation. Based on the integrated Intel UHD graphics, PCOM-B657VGL also offers 70% higher graphic and transcode performance which make it suitable for graphic-intensive applications including gaming, digital signage, smart retail and much more. In addition, PCOM-B657VGL also features the PCIe Gen 4 x16 on embedded x86 platform which doubles the data transfer rates over PCIe Gen 3 for higher bandwidth, lower latency, and lower power, helping to extend bandwidth to external PCIe Graphic Card for AI and AIoT application.

Featuring up to 8 cores/16 threads with 45W/35W, and 25W TDP, industrial use condition and ECC Support, PCOM-B657VGL offers long life product support of 10+ years and can simultaneously support 4 independent 4K displays selecting from three DDI, one VGA, and one dual channel LVDS(18b/24b) interface. PCOM-B657VGL can deliver superior performance in various environments. Its fully integrated and flexible I/O expansion making it the optimal choice for mission critical use conditions and AI edge computing applications in industrial automation, machine vision, communication, IoT, edge computing, medical equipment, transportation, automated test equipment.

Scalable COM Express modules with 11th Generation Intel processors integrating Industry 4.0-centric features, PCOM-B657VGL is the inflection point for manufacturers amid IT/OT convergence. It could be your ideal solution to defend against sudden and drastic environmental change or accelerate the operational efficiency that separates your business from the competition.

PCOM-B657VGL COM Express Type-VI Basic Module with Intel® 11th Gen H Processor

  • 11th Gen Intel® Core™, Celeron®, and Xeon® W-11000E Series processors in 10nm SuperFin Process technology
  • AI/DL Instruction sets Support (Intel VNNI, AVX-512, INT8, FP16)
  • Up to 8C/16T@45W and 25W with Industrial temperature SKUs
  • DDR4 SO-DIMM, PCIe Gen 4.0 x16, and 8x PCIe Gen 3.0 x1
  • Complete Support of 3x DDI, one VGA, and one dual channel LVDS(18b/24b)
  • Support Intel® TCC/TSN with 2.5GbE

For more information, please Click Here to view our Application Note for you!

影片

說明

PCOM-B657VGL is COM Express module based on Intel® 11th Gen H Processor. It is compatible with COMe 3.0 standard. The platform adopt 10nm++ process and support VNNI instruction set, offers advance computing power with 45W~25W thermal and industrial use condition for wide range applications. PCOM-B657VGL supports PCIe Gen 4.0 x16, and ECC and DDR4 SODIMMs Industrial 45W/35W, 25W and Intel TCC / TSN, which is suit for mission critical use conditions and AI edge computing with TSN. This module provides eight PCIe x1 , four USB 3.2 Gen 2×1, and four SATA III. The complete and flexible I/O capacity also mapped to wide range of industrial applications.

Facebook
LinkedIn
Twitter
Email

產品信息

COM Express Type-VI 模組化電腦搭載英特爾® 第11代 H處理器搭配DDR4 SO-DIMM記憶體, DDI, PCIe Gen 4.0插槽, USB 3.2 Gen2x1, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP/LVDS, SATA III and VGA
