| CPU and General | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Product | PCOM-B886 | ||||||||
| Form Factor | COM-HPC® Client Size-B (120x120mm) | ||||||||
| CPU | Ultra 9 285H | Ultra 7 265H | Ultra 7 255H | Ultra 5 235H | Ultra 5 225H | Ultra 7 265U | Ultra 7 255U | U Ultra 5 235U | Ultra 5 225U |
| Core/Thread | 6P+8E+2LPE/16T | 4P+8E+2LPE/14T | 2P+8E+2LPE/12T | ||||||
| Base Frequency | 2.9(P)+2.7(E) | 2.2(P)+1.7(E) | 2(P)+1.5(E) | 2.4(P)+1.8(E) | 1.7(P)+1.3(E) | ) 2.1(P)+1.7(E) | 2.0(P)+1.7(E) | 2.0(P)+1.6(E) | 1.5(P)+1.3(E) |
| Turbo Frequency | 5.4 | 5.3 | 5.1 | 5 | 4.9 | 5.3 | 5.2 | 4.9 | 4.8 |
| Cache | 24 | 24 | 24 | 18 | 18 | 12 | 12 | 12 | 12 |
| TDP | 65/45/35 | 65/28/20 | 28/15/12 | ||||||
| Graphics EU | 128 | 128 | 128 | 128 | 112 | 64 | 64 | 64 | 64 |
| Graphics Max Freq. | 2.35 | 2.3 | 2.25 | 2.25 | 2.2 | 2.1 | 2.1 | 2.05 | 2 |
| PCH | SoC | ||||||||
| Memory Type/Speed | 2x DDR5 C/SO-DIMM up to 96GB 6400MT/s | ||||||||
| ECC Memory Support | IBECC | ||||||||
| Temperature Range | 0 ~ 60 °C (32.0 ~ 140.0 °F) | ||||||||
| BIOS | AMI BIOS | ||||||||
| Storage | PCIe(NVMe) SSD up to 1TB | ||||||||
| I/O Interface | |||
|---|---|---|---|
| SATA | 2x SATA III | ||
| USB |
|
||
| Ethernet | 2x 2.5GbE LAN | ||
| PCIe |
|
||
| Legacy I/O |
|
||
| Security | TPM 2.0 | ||
| Display | Interface on Module | Carrier Output Option | Resolution |
| eDP | eDP up to HBR3 | 3840 x 2160@120Hz | |
| DDI 1/2/3 | DP up to HBR3 | 3840 x 2160@120Hz | |
| MECHANICAL & ENVIRONMENT | |
|---|---|
| Dimension | 120 mm x 120 mm (4.72″ x 4.72″) |
| Operating Temperature | 0 ~ 60 °C (32.0 ~ 140.0 °F) |
| Storage Temperature | -40 ~ 85 °C (-40.0 ~ 185.0 °F) |
| Certification | CE Marking/ FCC/ UKCA |
| OS | Windows 11/ Ubuntu |
| Portwell Special Feature | PET API |
| Ordering Guide | ||
|---|---|---|
| Product | P/N | Status |
| PCOM-B886-285H | TBD | In Development |
| PCOM-B886-265H | TBD | In Development |
| PCOM-B886-255H | TBD | In Development |
| PCOM-B886-235H | TBD | In Development |
| PCOM-B886-225H | TBD | In Development |
| PCOM-B886-265U | TBD | In Development |
| PCOM-B886-255U | TBD | In Development |
| PCOM-B886-235U | TBD | In Development |
| PCOM-B886-225U | TBD | In Development |
