COM Express Ā®

COM Express defines standardized form factors and pinouts for Computer-on-Modules

The standard includes the mini form factor (84 x 55 mm), the compact form factor (95 x 95 mm), and the basic form factor (125 x 95 mm)

IntelĀ® PTL-H; 4P+8E+4LPE; 12Xe GPU (120 TOPS), NPU 5 (50 TOPS); 2x DDR5 SO-DIMM to 128GB IBECC; 12 PCIe Gen4 lanes; USB3.2, SATA, DDI, eDP/LVDS; MIPI-CSI
COM ExpressĀ® Type6 Compact size module with IntelĀ® Atom™® x7000E/RE Series SoC DDR5 SO-DIMM, DDI, PCIe Gen 3, USB 3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA
IntelĀ® AtomĀ® x7000 series SoC based on Type 10 mini COM-ExpressĀ® module with LPDDR5 SDRAM
COM Express Type 7 Basic Module based on IntelĀ® XeonĀ® D-1800 Processors with Two Channels and Two SO-DIMM slots.
IntelĀ® AtomĀ® C3000/C3000-Refresh series SoC based on Type 7 Compact COM-ExpressĀ® module with up to Dual Channels and 2x DDR4 ECC SO-DIMM Socket
COM Express Type 6 Basic size module with Intel New Gen Core Ultra 200 Series Processor DDR5 SO-DIMM, DDI, PCIe Gen 4,USB 3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA
COM Express Type6 Compact size module with IntelĀ® 13th Gen P/U Processor DDR5 SO-DIMM, DDI, PCIe Gen 4, USB4, USB 3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA
COM-ExpressĀ® Type 7 Basic module with AMDĀ® Embedded RyzenTM V3000 CPU Family equipped on-module NVME SSD
COM Express Type 7 Basic Module based on IntelĀ® XeonĀ® D-1700 Processors with Three Channels and Four SO-DIMM slots
COM Express Type6 Basic size module with IntelĀ® 13th Gen H Processor DDR5 SO-DIMM, DDI, PCIe Gen 4, USB 3.2 Gen2, 2.5Gb Ethernet, discrete TPM 2.0, eDP, SATA
Mini-ITX size carrier board for COM Express Type6 module
Micro-ATX Form Factor Evaluation Carrier Board For Type 10 COM Express@ Rev 3.0 Module
COM Express Type-VI Basic module with IntelĀ® 11th Gen H Processor with DDR4 SO-DIMM, DDI, PCIe Gen 4.0, USB 3.2 Gen2x1, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP/LVDS, SATA III and VGA
IntelĀ® AtomĀ® x6000 series SoC based on Type 10 Mini COM-ExpressĀ® module with LPDDR4 SDRAM
IntelĀ® AtomĀ® Elkhart Lake series SoC based on Type 6 Compact COM-ExpressĀ® module with 2x DDR4 SD-DIMM Socket
IntelĀ® AtomĀ® E3800 series SoC based on Type 10 Mini COM-ExpressĀ® module with DDR3L SDRAM, NANDrive and USB 3.0
IntelĀ® AtomĀ® E3900 series SoC based on Type 10 Mini COM-ExpressĀ® module with LPDDR4 SDRAM, eMMC and USB 3.0
IntelĀ® AtomĀ® Apollo Lake series SoC based on Type 6 Compact COM-ExpressĀ® module with 2x DDR3L SD-DIMM Socket
Intel® Tiger Lake-UP3 Coreā„¢ Processor based on Type VI COM Express module with dual DDR4 SO-DIMM, DDI, eDP, Gigabit Ethernet, SATA 3.0, and USB 3.2
IntelĀ® Comet Lake-S Coreā„¢ Processor based on Type VI COM Express module with dual DDR4 SO-DIMM, DDI, LVDS, VGA, Gigabit Ethernet, SATA III, and USB 3.2 Gen2
IntelĀ® Coffee Lake-S Coreā„¢ Processor based on Type VI COM Express module with dual DDR4 SO-DIMM, DDI, LVDS, Gigabit Ethernet, SATA III, and USB 3.2 Gen2
IntelĀ® Coreā„¢ Whiskey Lake-U i7/i5/i3 series processor based on Type 6 Compact COM-ExpressĀ® module with 2x DDR4 SD-DIMM Socket
IntelĀ® XeonĀ® D-1600 series SoC based on Type 7 Basic COM-ExpressĀ® module
IntelĀ® AtomĀ® C3000/C3000-Refresh series SoC based on Type 7 Basic COM-ExpressĀ® module with 3x DDR4 ECC SO-DIMM Socket
Mini-ITX Form Factor Evaluation Carrier Board for Type 6 Com-ExpressĀ® Rev 2.1 Module
PCOM-C615 is PICMG 1.3 Full Size Form Factor Evaluation Carrier Board for COM ExpressĀ® Revision 2.0 Type VI Module. PCOM-C615 follows standard PICMG 1.3 golden finger pin definition and let customer save system total cost for easily upgrading modules

ATX Form Factor Evaluation Carrier Board for Type 6 Com-Express® Rev 3.0 Module

ATX Form Factor Evaluation Carrier Board for COM Express Revision 3.0 Type VII Module with 4x 10GbE Support with Inphi CS4227 PHY
IntelĀ® 7th Generaon Coreā„¢ Kaby Lake-S processors based on Type VI Compact-COM Express 2.0 module with DDR4 SDRAM on Two SO-DIMM slots, VGA, eDP, DP, Gigabit Ethernet, PCIE, SATA and USB
IntelĀ® Coreā„¢ 7thĀ Generaon Processor based on Type VI COM Express module with DDR4 SDRAM, VGA, LVDS, Gigabit Ethernet, SATA 3.0 and USB
Intel® Coreā„¢ Kaby Lake-U/Skylake-U i7/i5/i3 series processor based on Type 6 Compact COM-Express® module with 2x DDR4 SD-DIMM Socket
Intel® AtomTM N3000 series based TypeVI COM Express with DDR3L SDRAM, VGA, LVDS, USB 3.0, PCIE and surround design.Intel® AtomTM N3000 series based TypeVI COM Express with DDR3L SDRAM, VGA, LVDS, USB 3.0, PCIE and surround design.
Data protection is more and more important in real world since big data rising. Portwell adopt new Intel platform to provide highest secure logic. It help customer earn trust and business by securing important information anytime
PCOM-C640 is NANO-ITX carrier board with triple display, Gigabit Ethernet, Audio, USB 3.0, SATA. It’s a powerful carrier which is suitable for system.
