Portwell / Products / Medical-Grade Computers / Medical Box PCs / MEDS-7061
| Processor | Socket LGA1151 for Intel® Coffee lake Core™ i7/i5/i3®, up to 65W |
| Memory | 2x DDR4 SO-DIMM 2400/ 2666 memory up to 64GB |
| Storage | – 1x mSATA half size SSD – 2x 2.5″ SSD |
| OS Support | Windows 10, Linux |
| USB | USB3.0 x2 |
| Serial port | N/A |
| Ethernet | Gigabit LAN x2 |
| Display | mini-DP x2 |
| Audio | N/A |
| PCIe slot | – 1x PCIe x16 (x16 signal) – 1x PCIe x4 (x4 or x1 signal selectable) – 1x PCIe x1 (x1 signal) |
| Optional | M.2 Bluetooth & Wifi module |
| Power input | Power cord AC plug |
| Power limit | 500W |
| Power supply | 500W Flex-ATX power (Medical grade) |
| Dimension(Wx Dx H) | 170 x 400 x 204 mm |
