The rapid adoption of Industry 4.0 and smart manufacturing is driving high demand for reliable SMARC 2.2 module AGV and AMR solutions worldwide. Unlike conventional material handling equipment, today’s vehicles require an advanced autonomous mobile robot computer to navigate autonomously and avoid obstacles. They also need to communicate with factory management systems and make real-time decisions with minimal human intervention.
To achieve these capabilities, modern mobile robots must integrate multiple sensors like cameras, LiDAR, IMUs, and encoders. At the same time, they need to execute localization, path planning, and motion control. Consequently, these workloads require compact embedded computing platforms. These platforms must deliver reliable processing, deterministic responsiveness, low power consumption, and long-term availability.
As AGV and AMR technologies become more sophisticated, the computing platform has become one of the most critical design considerations. Depending on system requirements, embedded developers may choose between single-board platforms and modular architectures.
Some applications benefit greatly from hardware scalability and processor upgrade flexibility. For these cases, computer-on-modules offer a practical path to improve computing performance. They preserve application-specific carrier board designs, which reduces engineering effort and shortens time-to-market.
For AGV and AMR platforms, developers also require robust high-speed connectivity for multiple sensors and peripherals. Specifically, camera interfaces enable machine vision and object recognition. Meanwhile, CAN Bus remains a widely adopted communication interface for motor controllers, battery management systems, and industrial control devices. In addition, high-speed Ethernet supports fleet management and edge-to-cloud communication. Furthermore, multiple PCIe lanes provide flexibility for additional AI accelerators, wireless modules, or custom I/O expansion. Consequently, these requirements make computer-on-modules an increasingly attractive architecture for compact autonomous mobile systems.
Portwell PCOM-BC00 is designed specifically for compact embedded systems. It combines Intel Atom® x7000E/RE Series processors with the flexibility of the SMARC 2.2 standard. This provides an ideal computing foundation for modern, intelligent AGVs and AMRs.
Intel Atom® x7000E/RE processors power the PCOM-BC00 with up to 8 CPU cores and a 6W–15W TDP. It delivers an optimized balance between computing performance and energy efficiency. This helps maximize battery life for autonomous mobile platforms. The module integrates up to 16GB onboard LPDDR5 memory and up to 256GB onboard eMMC 5.1. This enables fast boot times, reliable local storage, and responsive execution of navigation and control software.
Its extensive I/O configuration supports the diverse connectivity requirements of mobile robots. It includes 4 PCIe Gen3 x1, 2 USB 3.2 Gen2, 6 USB 2.0, dual 2.5GbE, 2 UART, SATA, and triple display outputs. These are anchored by a standard DP++ with SKU specific options for HDMI®/DP and eDP/LVDS. Importantly, MIPI-CSI support allows direct integration of compact industrial cameras. This enables vision-based navigation, obstacle detection, barcode recognition, and AI inspection. The optional CAN bus interface simplifies communication with motor drives, battery management systems, and motion controllers. This ultimately reduces overall system complexity.
Factories continue their digital transformation. Consequently, AGVs and AMRs are evolving from simple transportation equipment into intelligent mobile computing platforms. They are now capable of perception, communication, and autonomous decision-making. This evolution requires embedded computing solutions that combine high integration, industrial reliability, scalability, and long lifecycle support.
The Portwell PCOM-BC00 SMARC 2.2 module addresses these challenges. It integrates Intel Atom® x7000E/RE processors with modern industrial connectivity, power-efficient operation, and a highly modular architecture. PCOM-BC00 can be deployed in warehouse logistics, factory automation, semiconductor manufacturing, electronics assembly, or intelligent material handling. It enables OEMs and system integrators to develop compact, reliable, and scalable AGV and AMR solutions. This results in shorter development cycles and a lower total cost of ownership. PCOM-BC00 combines efficiency, flexibility, and industrial-grade reliability. It provides an ideal embedded computing platform for intelligent AGV and AMR systems, accelerating development while supporting long-term deployment requirements.
