COM Express® Compact

COM Express® Compact (95 x 95mm): COMe Compact form factor (95 x 95mm) and type 6, type 7 pin-out

COM Express Type 6

The Type 6 COM-Express module is defined by PCI Industrial Computer Manufacturers Group (PICMG). The Type 6 COM-Express provides standardized module interfaces including storage, graphic control, video Interfaces (LVDS, VGA & DDI), and USB 3.0 to meet different application requirements from the various vertical market.

COM Express Type6 Compact size module with Intel® 13th Gen P/U Processor DDR5 SO-DIMM, DDI, PCIe Gen 4, USB4, USB 3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA

COM Express® Type6 Compact size module with Intel Atom® x7000E/RE Series SoC DDR5 SO-DIMM, DDI, PCIe Gen 3, USB 3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA

Intel® Atom® Elkhart Lake series SoC based on Type 6 Compact COM-Express® module with 2x DDR4 SD-DIMM Socket

Intel® Atom® Apollo Lake series SoC based on Type 6 Compact COM-Express® module with 2x DDR3L SD-DIMM Socket

Intel® Tiger Lake-UP3 Core™ Processor based on Type VI COM Express module with dual DDR4 SO-DIMM, DDI, eDP, Gigabit Ethernet, SATA 3.0, and USB 3.2

Intel® Core™ Whiskey Lake-U i7/i5/i3 series processor based on Type 6 Compact COM-Express® module with 2x DDR4 SD-DIMM Socket

Intel® Core™ Kaby Lake-U/Skylake-U i7/i5/i3 series processor based on Type 6 Compact COM-Express® module with 2x DDR4 SD-DIMM Socket

COM Express Type 7

The Type 7 Modules trades all audio and video interfaces, 2 SATA ports and four USB 2.0 for additional PCI Express lanes, 4x 10 Gb Ethernet ports and an NCSI management interface for the GbE port.

Intel® Atom® C3000/C3000-Refresh series SoC based on Type 7 Compact COM-Express® module with up to Dual Channels and 2x DDR4 ECC SO-DIMM Socket
